(Table 10, contd)
Event Codes
J1939 Code and Description PDL Code and Description
Troubleshooting Procedure
7105-31
Aftertreatment #1 Inconsistent Con-
figuration Detected
E1598 (2)
Aftertreatment #1 Inconsistent Configu-
ration Detected
Troubleshooting, “NOx Conversion Is Low”
7343-31
SCR Operator Inducement Override
Renewal Required
E1598 (2)
Engine Emissions Operator Induce-
ment Emergency Override Renewal
Required
Troubleshooting, “SCR Inducement Emergency Override”
7440-31
Aftertreatment Active Regeneration
Inhibited Due to Low Exhaust
Pressure
E1645 (1)
Aftertreatment Active Regeneration In-
hibited Due to Low Exhaust Pressure
Troubleshooting, “Diesel Particulate Filter Collects Excessive
Soot”
Event Codes in Perkins Data Link
(PDL) Code Order
Table 11 is a list of the event codes for the engine.
The event codes are listed in order of PDL codes.
The event codes are cross-referenced with the
appropriate procedure that can be used to
troubleshoot the code.
Table 11
Event Codes
PDL Code and Description J1939 Code and Description Troubleshooting Procedure
E171 (2)
Low Engine Oil Level
98-18
Engine Oil Level : Low - moderate se-
verity (2)
Troubleshooting, “Oil Level Is Low”
E171 (3)
Low Engine Oil Level
98-1
Engine Oil Level : Low - most severe
(3)
Troubleshooting, “Oil Level Is Low”
E232 (1)
High Fuel/Water Separator Water
Level
97-15
Water In Fuel Indicator : High - least
severe (1)
Troubleshooting, “Fuel Contains Water”
E232 (2)
High Fuel/Water Separator Water
Level
97-16
Water In Fuel Indicator : High - mod-
erate severity (2)
Troubleshooting, “Fuel Contains Water”
E360 (1)
Low Engine Oil Pressure
100-17
Engine Oil Pressure : Low - least se-
vere (1)
Troubleshooting, “Oil Pressure Is Low”
E360 (2)
Low Engine Oil Pressure
100-18
Engine Oil Pressure : Low - moderate
severity (2)
Troubleshooting, “Oil Pressure Is Low”
E360 (3)
Low Engine Oil Pressure
100-1
Engine Oil Pressure : Low - most se-
vere (3)
Troubleshooting, “Oil Pressure Is Low”
E361 (1)
High Engine Coolant Temperature
110-15
Engine Coolant Temperature : High -
least severe (1)
Troubleshooting, “Coolant Temperature Is High”
(continued)
58 UENR4469-36
Event Codes
