6.3 Setting into Operation
♦ Ifnecessary,mountthedriveunitontoaxingdeviceforwall-mounting(refertochapter4.1).
♦ InsertthebatterysetintothedriveunitandthePROLCunitintotheprotectioncoverandclosethecomplete
system(refertochapter4.2b-d).
♦ Determinethedischargeperiod(refertochapter6.7).
♦ SetvolumeofPROLCunit,dischargeperiod,outletsofMP-6,andthePINviabuttonsondisplay(referto
chapter6.8).
♦ Switch-onthelubricationsystem(refertochapter6.5).
♦ Carryoutanadditionaldischarge(refertochapter6.8).
IfthedrivemotorhasstartedandthegreenLEDislit,thelubricatorhasstartedtodischarge.Thedisplay
indicatestheremainingvolume(%Vol.)ofthePROLCunit.
The operator must always check the customer-specic settings and if necessary change them before the
lubricator is set into operation!
6.4 During Operation
♦ Carryoutregularinspectionsduringtheoperation.Youshouldpayspecialattentionwithregardtoleakage
andtotheconditionofthelubricator!
♦ Checktheconditionofthelubricanttubeandtheconnectionsregularly!
♦ CheckthellinglevelofthetransparentPROLCunitregularly!
♦ Afteroneorseveraladditionaldischarges,youhavetocalculatethereduceddischargeperiodandnotethis
onyourlubricationandmaintenanceschedule.
♦ Ifamalfunctionisindicatedonthedisplay,youcandeterminethecauseusingthetroubleshootingguide
(refertochart7,chapter8.2).Ifthefaultcannotbexed,pleasecontactyoursupplierfortechnicalsupport.
Additional discharges and long machine standstills must always be taken into account with regard to the
remaining discharge period of the lubricator.
6.5 Switching the Lubrication System On
Toswitchthelubricationsystemon(refertogure13),keeptheON/OFF/SELECTbuttonpresseduntilthe
indication(“ ”)onthedisplayisreplacedbyanindicationoftheremainingvolume–e.g. %VOL(witha
newPROLCunit)–andthegreenLEDstartsblinking.
6.6 Switching the Lubrication System Off
Toswitchthelubricationsystemoff(refertogure14),keeptheON/OFF/SELECTbuttonpresseduntilthe
displaynolongerindicatestheremainingvolume–%VOL–butindicates(“
”)instead.Whenthelubrication
systemisswitchedoff,allofthesettingsaresaved.Thismeansthatifyoustartthelubricatoragain,itwilltake
uptheoperationatthepointwhereithadbeenswitchedoff.
ON/OFF
SELECT
%Vol.
LC 500
gure13
ON/OFF
SELECT
%Vol.
LC 500
gure14
