Perma PRO 500 - Technical Data for MP-6 Distributor; MP-6 Distributor Specifications

permaPROMP-6Distributor-6-
3. Technical Data
perma PRO MP-6 Distributor
Length 148mm
Diameter 64mm
Weight ca.0.960kg
Number of outlets
2minimum
6maximum
Maximum working pressure 25bar(360psi)
Lubricants GreasesuptoratedconsistencyNLGI2
Ambient temperature -20°Cto+60°C/-4°Fto+140°F
Power supply fromthelubricatorviaconnectingcable
Emission sound pressure level <70dB(A)
Connection thread for lubricators
of the PRO range
G3/8inside
Connection thread for grease line G1/8inside
Diameter of grease line 8x1.5(inner-Ø5mm)
Length of the grease line
admissibletotallengthperpipeupto5m; for details please
regard operating manual PRO/PRO C chapter 3, chart 1
Storage conditions Dry,dust-freeattemperaturesof+20°C±5°C/68°F±9°F
Protection class IP54
chart1
gure1
148
max.Ø64
SW19
G3/8inside
37
G1/8
