3.1 Design of the perma MP-6 Distributor
Eachdistributor(refertogure2)issuppliedwithallnecessaryaccessories(refertogure3).Theuserhasto
installtherequiredconnectionsorplugsandmustconnectthedistributortoalubricatorofthepermaPROrange.
ThepermaMP-6distributorconsistsof:
Housingcontainingthedriveunitandthe
distributionsystem(max.6outlets).
gure2
max.6mm
max.6mm
max.6mm
3.2 Accessories
Connections(6pcs.)forgreaselines
Plugs(4pcs.)forsealingtheoutlets
whicharenotused.
Connectingcable(short)
forpowersupplyofthedistributor
andforcommunicationbetween
distributorandlubricator.
gure3
