Perma PRO 500 - Operation and Control for MP-6 Distributor; During Operation; Switching System On;Off; Determining the Discharge Period

permaPROMP-6Distributor-12-
Outlets
1
3
2
4
5
6
Outlets
1
3
2
4
5
6
%Vol.
LC 500
ON/OFF
SELECT
ON/OFF
SELECT
Outlets
1
3
2
4
5
6
%Vol.
LC 500
5.4 During Operation
♦ Carryoutregularinspectionsduringoperation.Youshouldpayspecialattentiontoleakage,tothecondition
ofthedistributor,andthecompletelubricationsystem!
♦ Regularlychecktheconditionofthegreaselinesandtheconnections!
♦ RegularlycheckthefillinglevelofthetransparentPROLCunitofthelubricator!
♦ Afteroneorseveraladditionaldischarges,youhavetocalculatetheremainingdischargeperiodandmarkit
inyourlubricationandmaintenanceschedule.
♦ Ifamalfunctionisindicatedonthedisplay,youcandeterminethecauseusingthetroubleshootingguide
(refertochart3,chapter6.2).Ifthefaultcannotbefixed,pleasecontactyoursupplierfortechnicalsupport.
Additional discharges and long machine standstills must always be taken into account with regard to the
remaining discharge period of the lubrication system.
5.5 Switching the Complete Lubrication System On
ToswitchonthelubricationsystemPRO (refertofigure8),keeptheON/OFF/SELECTbuttonofthelubricator
presseduntilthedisplaynolongershows“ ”.
TostartthelubricationsystemPRO Cyouhavetoswitchonpowersupply.
Afterswitch-on,thelubricatorautomaticallydoesaninitialization(systemrecognizestheactivatedoutlets).During
initialization,theoutlets(representedbysquares)inthedisplayareblinking.Activatedoutlets(squares)willbe
blackened,inactiveoutlets(squares)areblank.Whentheinitializationprocessisfinished,thegreenLEDblinks
andthedisplayshowstheoutlets(squares),theremainingvolume(inpercent),andtheLCunitsize(250and
500cm
3
).
5.7 Determining the Discharge Period
TherequireddischargeperiodmustbedeterminedusingtheOperatingInstructionsoftheconnectedlubricator.
YouhavetotakeintoaccountthatthedistributorpermaMP-6isabletosupplyanequalamountoflubricantto
upsixlubricationpoints.
Whendeterminingthedischargevolume,youhavetomultiplythenumberofopenoutletswiththerequired
dischargevolumeperoutlet.Withtheresultofthiscalculationyoucandeterminethesettingpointofthe
dischargeperiodusingtheOperatingInstructionsoftheconnectedlubricator.
gure9
OnlywithPRO
gure8
OnlywithPRO
Thelubricationsystemis
switchedoff.
Initializationprocess
Thelubricationsystemison.
Whenthelubricationsystemisswitchedonforthersttime,theinitializationiscarriedoutautomatically
bythelubricator.Theoutlets(squares),theremainingvolume(inpercent),andtheLCunitsize(250or
500cm
3
)areonlydisplayedaftertheinitializationprocessisnished.
5.6 Switching the Complete Lubrication System Off
ToswitchoffthelubricationsystemPRO(refertogure9),keeptheON/OFF/SELECTbuttonofthelubricator
presseduntilthedisplaynolongerindicatestheremainingvolumebutindicates“ ”instead.
TostopthelubricationsystemPRO C youonlyhavetoswitchonpowersupply.
Whenthelubricationsystemisswitchedoff,allofthesettingsaresaved.Thismeansthatifyoustartthe
lubricatoragain,itwilltakeupoperationatthepointwhereithadbeenswitchedoff.
