4. Assembly and Mounting of the Distributor
4.1 Mounting the Connections
♦ Chosethenumber(6max.)andthepositionoftheoutletsthatyouintendtouse.
♦ Screwtheconnectionstightly(max.torqueof2Nm)intotheoutletstobeopened(refertogure4).
♦ Sealalltheremainingoutletsusingtheenclosedplugs.
4.2 Distributor Housing
Neverloosenthesescrewsatthebottom
ofthedistributorandneveropenthehousing.
gure5
gure4
1
2
3
4
5
6
