Caption for Chart on Left Side
Instructionsshouldbefollowedfromtoptobottomandfromlefttoright(alsorefertochart3).Theinstructions
correspondtotheoperatingsequenceontheturned-offlubricationsystempermaPRO.Congurationisalso
possibleifpermaPROisOn.
chart6
Function shortpush longpush blinkingdisplay goto
Symbol
CONFIGURATION SECTIONS (see vertical bar, chart 5)
I N T R O
INTROinforms

Info
andasksforthecurrentPIN.

PINEntry
C O N F I G U R A T I O N M E N U E
Settingscanbechangedinthecongurationmenuwithitsdifferentsections(LC,Time,Outlets,PIN).
LC
YoucanchangethePROLCunitsizefromLC250toLC500andbackbypushingtheON/OFF/SELECTbutton
(refertochapter7.1and7.2).
Time
Thedischargeperiodcanonlybesetinonetypeofcalendarunit(i.e.eitherMonths,WeeksorDays).When
thehighestunitsizeisreached,countingstartsagainwithnumber“
”.
Outlets
IfaMP-6distributorisconnected,outlets1-6canbesetindividually.Theactivatedoutlets1-6aredisplayed
withalled-insquareinthedisplay(pleaserefertotheoperatinginstructionoftheMP-6distributorformore
details).
PIN
WestronglysuggesttoenterapersonalPINinordertoprotectyoursettingsfromunauthorizedaccess.The
PINcanonly be changed during initial conguration or after a PIN-reset.APIN-reset(shortpushofbut-
tons:left-left-right-right-leftintheINTRO-Info-menu)changesyourpersonalPINbackto“
”.ThePIN-reset
wassuccessfulwhenthedisplayedtimedisappearsforasecondandthencomesbackon.Allothersettings
remainunchanged.
Save or Reject Changed Settings
ThedisplaysettingscanbesavedwithalongpushoftheMODE/SAVEbutton.Ifyoudonot wanttosaveyour
changestosettingsthatarecurrentlydisplayedinthecongurationmenu(LC,Time,Outlets,PIN),pressthe
ON/OFF/SELECTbuttonuntilthedisplayshowseither(“
”)forOffortheremainingvolumeofthePROLCunit
in%VOL.Allothersettingsandalreadysavedchangesremainvalid.
Automatic Termination of the Conguration Mode
Ifyoudonotpressabuttoninthecongurationmenufor180seconds,thecontrolsystemisautomatically
switchingbacktothepreviouslysetmode(“On”or“Off”)withoutsavingthechanges.Allothersettingsand
alreadysavedchangesremainvalid.
Additional Discharge
Withanadditionaldischarge,alubricationpointcanbesuppliedwithanadditionalamountofthelubricant.
Foranadditionaldischarge,thelubricationsystemmustbeswitchedon(displayshowsremainingvolume)and
youhavetopressbothbuttonssimultaneouslyandholdthemdown(refertogure15).
gure15 LubricatorOn Foranadditionaldischarge,pressbothbuttonsatthe
  sametimeandholdthemdown(>4sec.)
Anadditionaldischargeisonlypossibleattemperaturesabove0°C/32°F(gure16,icecrystalisnotvisible)
andwhenthelubricationsystemisnotcurrentlyconductingaregulardischarge.
Everyadditionaldischargereducestheremainingdischargeperiodsinceanincreasedamountofthelubricant
hasbeensupplied.Thismustbetakenintoaccountinyourlubricationandmaintenanceschedule.Acalculation
ispossiblewiththeformulafromchapter6.9andwiththeremainingvolumewhichisdisplayed.
The time between two additional discharges is 30 seconds. Each additional long push of both buttons
(simultaneously, gure 15) during this time is being registered and will lead to even more additional
discharges. The system remembers a max. of 5 additional discharges.
MODE
SAVE
ON/OFF
SELECT
%Vol.
LC 500
