Perma PRO 500 - Lubrication System perma PRO; Component Overview; Display and Drive Unit Details

permaPRO -1-
Config.
TimePIN
Outlets
1
3
2
4
5
6
Days
We eks
Months
%Vol.
LC250
Display
Drive Unit
Protection cover
Withbayonetcatchforquick
opening/closing.
PRO LC unit
(LubricationCanister)
Cartridge,piston,spindle
lledwithlubricant.
Red LED
Additionalmalfunction
indication.
Push Button: MODE/SAVE
Leadstothe
CongurationMenuandsaves
theselectedsettings.
Drive Unit
Containselectronics,
motor,andpumpsystem.
Con guration menu
Forenteringthesettings.
Outlets 1 - 6
Showsactivatedoutlets
Number
Showsremainingvolume,
dischargeperiod,outletno.,
PIN,andmalfunctioncodes.
Setting Mode
Displaysthecurrentsettingindays,
weeks,ormonths.
Size of PRO LC unit
DisplaysvolumeofLCunit
(250or500
cm
3
)
Ice icon
Indicateseitherthatthetemperature
fellbelow0°C/32°F(iconblinking),
orthatthelowtemperatureshutoff
(below-20°C/-4°F)hasturnedthe
systemoff(iconpermanent).
Battery Compartment
Forinsertionofbattery
set
Catch
Fordrivingthespindle
Interlocking Teeth
Topositionthe
PROLCunit.
No function!Settingof
PROLCunitsizeisdone
viamenuonthedisplay.
PRO
Battery B
PRO Battery
B plus
Lubrication System perma PRO
Remaining volume
of the PRO LC unit
Showsthelubricant
remaininginthePRO
LCunitin%volume.
Content
Descriptionofthellingdateandthe
containedlubricant.
Type
ProducttypeandsizeofPRO
LCunit
Display
Informsaboutoperatingconditions,
malfunctions,settings,andthe
lubricantvolumeleftinthe
PROLCunit.
Push Button: ON/OFF/SELECT
ToturnsystemONorOFFandto
changesettings.
Green LED
Additionalindicationofthecurrent
operatingcondition.
Connector for distributor
PRO MP-6
Connection thread
G3/8forapplicationinto
alubricationpointorfor
connectingagreasetube.
