Input
63
Group
Parameter
Description
User level
Setting range
Set value
11 1100 Operating mode of the stepping motor 1
(Puller, differential adjustment etc.)
C 0 - 1 1
1101 Direction of rotation of the stepping motor 1
ON = anti-clockwise direction
OFF = clockwise direction
C ON - OFF ON
1102 Stepping mode of the stepping motor 1
1 = full step
2 = half step
3 = quarter step
4 = eighth step
C 1 - 4 2
1103 Maximum power for the stepping motor 1
[%]
C 1 - 100 90
1104 Reducing power for the stepping motor 1
[%]
C 0 - 60 50
1105 Start/stop time for the stepping motor 1
(Time for one step in start/stop speed)
C 10 - 4000 250
1106 Pulse time for the stepping motor 1
(Time for one step in pulse speed)
C 10 - 4000 820
1107 Acceleration of the stepping motor 1
(Percentage increase in the speed from start/
stop to the pulse speed)
C 1 - 50 8
1108 Number of brake steps for the stepping mo-
tor 1
C 1 - 50 5
1110 Offset after reference run C 0 - 30 5
1111 Acceleration of the stepping motor 1 C 0 - 100 100
