Mixing Pump PFT G4
Operation
44 2007-09-05
Pos: 6.16 /KN2006-SM/Be dienung/006 1.1 Aussc halten_Titel @ 9\mod_1 144405011820_293361. doc @ 293692
6.5 Switching off
Pos: 6.17 /KN2006-Pr ojekte/Knauf/Bedien ung/Mischpumpe PFT G4/1. 1 Ausschalten @ 36\mod_ 1177340654631_2933 61.doc @ 445888
1. Position the selector switch "Manual-O-Auto" to "O".
2. Pump out residual material until water escapes.
Fig. 37: Close air cock
3. Close air cock (Fig. 37/arrow) on the sprayer.
4. Switch off the machine via the "Operation OFF" pushbutton.
Fig. 38: Switching off the compressor
5. Switch off the compressor via the red button (Fig. 38/arrow).
