PFT G4 - Fault Indications

Mixing Pump PFT G4
Troubleshooting
2007-09-05 55
Pos: 7.15 /KN2006-SM/S törungen/004 Störung sanzeigen/004 1.1 Stör ungsanzeigen_Tit el @ 9\mod_114444315035 4_293361.doc @ 293699
7.2 Fault indications
Pos: 7.16 /KN2006-SM/S törungen/004 Störung sanzeigen/004 1.1. 0 Folgende Einric htungen zeigen Störungen an: @ 9\mod_1144443189413_2 93361.doc @ 293700
The following devices indicate operational issues:
Pos: 7.17 /KN2006-Pr ojekte/Knauf/Störu ngen/Mischpumpe PFT G4/S törungsanzeigen @ 13\ mod_1152713650675_2 93361.doc @ 298841
Fault indications
Fig. 58: Fault indicator lights
Pos. Warning signal Description
1 Indicator light –
yellow (Fig. 58/1)
Is illuminated if the sense of motor
rotation is wrong.
Is illuminated if a phase is missing in
the feed line.
2 Indicator light –
red (Fig. 58/2)
Is illuminated if the motor protection
switch is faulty.
