Mixing Pump PFT G4
Structure and function
26 2007-09-05
Pos: 4.8 /KN2006-SM/Auf bau und Funktion/004 1. 1 Baugruppenbeschrei bung_Titel @ 9\mod_11440 46217018_293361.doc @ 293622
4.3 Module description
Pos: 4.9 /KN2006-Pr ojekte/Knauf/Aufbau und Fu nktion/Mischpu mpe PFT G4/Baugruppenbesc hreibung Text @ 12\mod_115 2023193560_293361. doc @ 298810
The PFT G4 Mixing Pump consists of the following major
components:
Pos: 4.10 /KN2006-Pr ojekte/Knauf/Aufbau un d Funktion/Mischpu mpe PFT G4/Baugruppen @ 12\ mod_1152023931951_293 361.doc @ 298806
Fig. 7: Material container
 Material container with frame and protective grille
Fig. 8: Mixing pipe with motor
 Mixing pipe with motor and pump unit
Fig. 9: Compressor
 Air compressor K 2
