PFT G4 - Check the debris collector sieve

Mixing Pump PFT G4
Maintenance
2007-09-05 65
Pos: 8.23 /KN2006-Pr ojekte/Knauf/W artung/Mischpumpe PF T G4/1.1.1 Schmutzfängersieb r einigen @ 36\mod_117 7346898000_293361. doc @ 446059
8.4.3 Clean the debris collector sieve
 To be performed by the operator.
Fig. 65: Debris collector sieve
1. Unscrew the pressure reducer's screw plug (Fig. 65/1).
2. Take out the debris collector sieve (Fig. 65/2) and clean it
3. Replace debris collector sieve if there is heavy fouling.
4. Insert the debris collector sieve and screw in the plug screw.
