PFT G4 - Page 73

Mixing Pump PFT G4
Replacement part lists
2007-09-05 73
Pos. Quantity Item no. Designation
1 1 20 20 78 19 Hex bolt M8 x 16 with collar
2 1 00 00 21 13 Protective grill with tubular steel frame
3 1 00 00 13 40 Anti-dust sheet G 4 RAL 2004
4 2 20 10 28 06 Rubber support strips 20x15x200 single-side adhesive coating
5 2 20 10 10 10 Cotter pin D 4.5 with ring
6 2 20 20 78 10 Hex bolt M 8 x 25 DIN 933 galvanized
7 2 20 20 64 00 Hex nut M 8 DIN 934 galvanized
8 2 20 20 78 00 Hex bolt M 8 x 30 DIN 933 galvanized
9 2 20 20 72 00 Lock nut M8 DIN 985 galvanized
10 2 20 10 31 10 Fold away carrying handle 340 mm
11 2 20 20 61 00 Hex bolt M 8 x 20 DIN 933 galvanized
12 2 20 20 64 00 Hex nut M 8 DIN 934 galvanized
13 1 20 10 26 10 Fastening clamp - water fitting G4 galvanized
14 4 20 20 96 02 Hex bolt M10 x 20 DIN 561 galvanized (setscrew)
15 1 20 20 96 01 Hex bolt M10 x 45 DIN 933 galvanized
16 1 00 01 13 86 Arresting lever G 4 with rubber cap RAL2004
17 1 00 01 04 62 Plastic handle 25x12 arresting lever
18 1 00 00 25 84 Arresting lever G 4 1 latch RAL2004
19 1 00 08 80 29 Eccentric bush MS for G 4 arresting lever
20 1 20 20 72 10 Lock nut M 10 DIN 985 galvanized
21 1 00 05 79 91 Magnet/safety sensor
22 2 20 20 71 16 Hex bolt M6 x 12 DIN 933 galvanized
23 1 00 08 42 63 Holder limit switch material container G 4/G 5 ULC RAL2004
24 3 00 00 11 63 Steering roller 230 mm black cover
25 1 00 00 11 64 Double stop - steerable castor 230 mm black cover
26 1 20 20 79 50 Ring nut M8 DIN 582 galvanized
27 1 20 10 14 01 Cover cleaning opening (exterior)
28 1 00 00 23 58 Sealing disk cleaning opening D=173 mm
29 1 20 20 78 01 Hex bolt M 8 x 16 DIN 933 galvanized
30 1 20 10 11 00 Seal drain opening G 4 sponge rubber 20 x 15 x 670
31 1 20 10 33 00 Material container with frame G 4
