Mixing Pump PFT G4
Replacement part lists
2007-09-05 75
Pos. Quantity Item no. Designation
1 1 00 07 27 90 Cellular wheel nut M24 galvanized
2 1 20 10 15 00 Cellular wheel G 4
3 1 20 10 18 10 Cellular wheel fastening plate
4 4 20 20 91 10 Spring ring B 12 DIN 127 galvanized
5 4 20 20 90 00 U-washer B 13 DIN 125 galvanized
6 4 20 20 99 61 Hex bolt M12 x 20 DIN 933 galvanized
7 1 00 07 18 52 Gear motor ZFQ38 0.75KW 31 rpm 230/400V 60Hz RAL2004
8 1 20 10 15 02 Spacer disk cellular wheel 1.5 mm galvanized
