Mixing Pump PFT G4
Replacement part lists
2007-09-05 77
Pos. Quantity Item no. Designation
1 1 00 04 76 21 Tilt flange G 54 with pipe bracket RAL2004
2 1 00 04 80 15 Sealing cap PVC 1" (round, black)
3 1 00 05 36 36 Gear motor ZF38 5.5kW 381 rpm 60Hz RAL2004
4 1 20 42 41 22 Motor connection cable 1.9 m CEE connector 4x 32A 9h blue
ring bolt 5 mm
5 1 20 42 76 02 CEE connector 4 x 32A 9h blue no. 263
6 1 00 00 22 97 Skintop gland PG 21
7 1 20 10 29 01 Protective tube for driver claw G4
8 2 20 20 78 00 Hex bolt M 8 x 30 DIN 933 galvanized
9 4 20 20 72 00 Lock nut M8 DIN 985 galvanized
10 2 20 20 78 01 Hex bolt M 8 x 35 DIN 933 galvanized
11 1 00 06 18 58 Driver claw cast G4 with round catch funnel
12 2 20 20 72 00 Lock nut M8 DIN 985 galvanized
13 2 00 02 32 71 Hex bolt M 8 x 40 DIN 931 galvanized
14 1 20 10 23 20 Mixing pipe cleaner D-pump and R-pump galvanized
15 1 20 10 35 10 Mixing helix G 4/G 5 hardened RAL2004
16 1 00 09 12 89 Cleaner shaft galvanized
17 1 20 20 16 50 Geka coupling blind cover
18 3 20 20 17 00 Seal Geka coupling (PU=50 pcs.)
19 2 20 20 11 00 Geka coupling 1" IT
20 1 20 10 06 50 Mixing pipe with cylinder without tilt flange G 4 with protective
bracket
21 1 20 10 12 02 Hinge bolt motor tilt flange galvanized
22 1 20 10 10 10 Cotter pin D 4.5 with ring
23 1 20 10 09 00 Seal tilt flange G4 sponge rubber 20 x 1
24 1 00 05 79 92 Magnetic activator for safety sensor
25 1 00 08 42 65 Holder limit switch an the tilt flange G 4/G 5 ULC RAL2004
26 2 20 20 71 16 Hex bolt M6 x 12 DIN 933 galvanized
27 1 20 20 85 22 Cotter bolt 8 H11 x 58 x 54 with washer
28 1 20 10 08 01 Snap closing with safety lock
