PFT G4 - Page 79

Mixing Pump PFT G4
Replacement part lists
2007-09-05 79
Pos. Quantity Item no. Designation
1 1 00 08 94 32 Suction flange D-pump with O-ring L=200 galvanized
2 1 20 10 42 30 O-ring 117 x 5 for suction flange
3 1 00 08 94 31 Suction flange D-pump for O-ring L=200 galvanized, yellow
4 4 20 20 99 21 Collar nut M16 DIN 6331 galvanized
5 4 20 20 99 20 Hex nut M 16 DIN 934 galvanized
6 1 20 20 03 30 Coupling reduction 35V-25V part LW 24
7 1 00 08 08 58 Mortar pressure manometer 35 mm cpl.
8 1 00 08 15 52 Manometer 0-100bar glycerin filled 1/2" with remote seal VA
9 1 20 20 07 90 Coupling 35M-part 1 1/4" IT with seal
10 1 00 00 17 92 Double nipple 1 1/4" x 60 no. 23 galvanized
11 1 00 04 16 64 Pressure flange D-pump G 4 galvanized 1 1/4" IG
12 1 20 11 87 80 Tension rod M16 x 370 mm (1 set =2 pc.)
13 1 20 11 55 10 Stator D6-3 maintenance-free orange
14 1 20 11 30 00 Rotor D6-3
