PFT G4 - Page 81

Mixing Pump PFT G4
Replacement part lists
2007-09-05 81
Pos. Quantity Item no. Designation
1 1 20 41 90 21 Microfuse 5 x 20, 2.0 A
2 2 20 41 90 30 Microfuse 5 x 20, 0.5 A
3 1 00 02 22 25 Foam rubber block for fuses
4 1 00 00 69 19
Control transformer 209/220 V 48 V (70 VA) micro fuse 20 mm
in length
5 3 20 41 90 30 Microfuse 5 x 20, 0.5 A
6 3 00 01 24 75 Fuse insert holder round/sw bayonet
7 1 20 41 90 21 Microfuse 5 x 20, 2.0 A
8 1 00 00 73 73 Fuse insert holder rectangular/orange
9 1 00 08 11 09 Coupler relay 48 V AC/DC 50-60 Hz 2 change-over contact
10 1 00 00 93 70 Motor protection switch 1.6-2.5 A PKZM 0-2.5
11 1 00 02 14 01 Auxiliary contact NHI-11-PKZO
12 1 00 02 21 40 Motor protection switch 2,5-4 A PKZM 0-4
13 1 00 02 14 01 Auxiliary contact NHI-11-PKZO
14 1 20 45 27 51 Phase-sequence relay 200-500 V with 2 change-over contacts
15 1 00 02 14 01 Auxiliary contact NHI-11-PKZO Klöckner/Möller
16 1 00 02 21 43 Motor protection switch 16-20 A PKZM 0-20
17 1 00 00 25 68 Air protection DIL 0AM 42 V
18 1 00 00 25 67 Auxiliary contact 22 DIL M
19 1 00 02 14 01 Auxiliary contact NHI-11-PKZO Klöckner/Möller
20 1 00 00 93 71
Motor protection switch 10-16 A PKZM 0-16 complete with
auxiliary contact
21 1 20 45 52 00 Main reverse switch
22 1 20 45 52 01 Knob for main reverse switch item no. 20455200
23 1 00 00 22 50 Indicator light, plug socket yellow without bulb, front install
24 1 20 45 91 01 Bulb 42 V 2 W plug socket BA 9S
25 1 20 44 45 00 Key for control panel
26 1 00 03 62 49 Lock control panel (double mandrel)
27 1 00 04 31 07 Door G 4 SUPER RAL7032
28 2 20 45 55 00 Manual-0-Automatic switch 400 V
29 3 00 04 11 27 Skintop cable gland M 20 x 1.5
30 3 00 04 11 45 Counter nut skintop M 20 x 1.5
