Mixing Pump PFT G4
Replacement part lists
86 2007-09-05
Pos. Quantity Item no. Designation
37 2 20 20 29 00 Hose clamp 28-31 PU=10 pc.
38 1 20 20 30 05 Hose kink protection for 3/4" water/air hose 580 mm
39 1 20 21 36 19 Water/air hose 3/4" x 22.83 inch
40 1 20 19 04 42 Hose coupling 1/2" OT socket 3/4"
41 2 20 20 36 10 Angle 1/2" IT-OT no. 92 galvanized
42 1 20 21 52 00 Stop cock 1/2" without drain
43 1 20 15 20 00 Collector sieve for Geka coupling
44 1 20 20 78 00 Hex bolt M8 x 30 DIN 933 galvanized
45 1 20 20 64 00 Hex nut M8 DIN 934 galvanized
46 1 20 10 26 11 Clamp water flow meter 150-1500 l/h
47 1 20 21 60 10 Manometer 0-6 bar 1/4" rear, D = 63 mm
48 1 20 21 60 00 Manometer 0-10 bar 1/4" bottom, D = 63 mm
