3 Monitoring SpO2
32
Connecting SpO2 Sensors
1 Connect the sensor to the single patient Mobile CL SpO
2
Cradle (if not already connected).
2 Insert the SpO
2
Pod into the Mobile CL SpO
2
Cradle. The correct orientation is indicated by a
matching blue dot inside the cradle.
CAUTION
Make sure that the contacts of the SpO
2
Pod and the sensor are dry and free of residues.
3 Secure the cradle on the patient's arm using the wristband.
a. Feed the free end of the wristband through the slot in the cradle, starting from the underside
of the cradle.
b. Slide the wristband onto the patient's arm and pull the free end until the wristband fits snugly.
c. Close the wristband using the Velcro patch on the free end of the band.
