10 Specifications
73
Measurement Range 30 to 300 bpm
Accuracy ±2% or 1 bpm, whichever is greater
Resolution 1 bpm
Sensors
LED Power Dissipation Temperature rise at sensor skin interface in compliance with ISO 9919
Optical Output Power ≤15 mW
Wavelength Range
Information about the wavelength range
can be especially useful to clinicians (for
instance, when photodynamic therapy is
performed)
500 to 1000 nm
For further information on accessory specifications, refer to the accessory Instructions for Use.
Display Specifications
Type monochrome (4 gray scales), passive LCD (STN), positive/transflective
Viewing Area 25.6 mm x 19.2 mm
Dot Size 0.2 mm x 0.2 mm
Resolution 128 x 96 pixel
Backlight white LED
Sounds
Hardkey operation tone
INOP tone
Battery
Integrated rechargeable Li-Ion battery with battery gauge and cycle counter
Runtime (fully charged battery) Continuous measurement:
Typically 24 hours
Intermittent measurement:
Typically 60 hours with repetition interval of 2 minutes
Typically 3 days with repetition interval of 5 minutes
Charging Time max 2.5 hours
Short Range Radio Specifications
Type built in interface with integrated antenna
Technology IEEE 802.15.4
Frequency band 2.4 GHz ISM (2.400 - 2.483 GHz)
Modulation DSSS (O-QPSK)
Bandwidth 5 MHz
Effective radiated power (ERP) max. 0 dBm (1 mW)
Electronic Article Surveillance (EAS)
EAS tag inside the housing
Real Time Clock Accuracy
less than 5 seconds per day (typically) as long as device is in power state
"Device on" or "Device off". Automatically synchronized with assigned
host system.
Performance Specifications
