10 Specifications
82
Performance Specifications
Display Specifications
Type monochrome (4 gray scales), passive LCD (STN), positive/transflective
Viewing Area 25.6 mm x 19.2 mm
Dot Size 0.2 mm x 0.2 mm
Resolution 128 x 96 pixel
Backlight white LED
Short Range Radio Specifications
Type built in interface with integrated antenna
Technology IEEE 802.15.4
Frequency Band 2.4 GHz ISM (2.400 - 2.483 GHz)
Modulation DSSS (O-QPSK)
Bandwidth 5 MHz
Effective Radiated Power (ERP) max. 0 dBm (1 mW)
WLAN Specifications
Type Internal wireless adapter
Technology IEEE 802.11a/b/g
Frequency Band USA: 2.400 - 2.483 GHz, 5.15 - 5.35 GHz, 5.725 - 5.825 GHz
Europe: 2.400 - 2.483GHz, 5.15 - 5.35 GHz, 5.47 - 5.825 GHz
Japan: 2.400 - 2.483GHz, 4.90 - 5.091 GHz, 5.15 - 5.25 GHz
China: 2.400 - 2.483 GHz, 5.725 - 5.85 GHz
Modulation Technique 802.11b/g
DSSS (DBPSK, DQPSK, CCK)
OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
802.11a
OFDM (BPSK, QPSK, 16-QAM, 64-QAM)
Effective Radiated Power (ERP) 2.4GHz Band - max. 22 dBm
5GHz Band - max. 20.5 dBm
Realtime Clock Accuracy
less than 5 seconds per day (typically) as long as device is in power state
"Device on" or "Device off". Automatically synchronized with assigned
patient monitor/telemetry device.
USB Interface
Standard USB 2.0 full speed Device Port
Power Input 4.5V - 5.5V (3W)
power requirement for service and upgrade of connected Cableless
Measurement devices 2.5W
Connector USB series “Standard-B” receptacle
LAN Network
