Phoenix Contact CAPAROC Series User Manual

The CAPAROC product family
109745_en_01 PHOENIX CONTACT 13 / 66
2.4.4 Housing versions, design, and dimensions
Figure 2-5 Housing versions
PM PN
PM S-R
PD 0V
E1
E2 E4
Table 2-5 Overview of housing versions
Housing
type
Special feature Example Design Dimensions
PM PN power module with PROFINET CAPAROC PM PN Figure 2-6 on
page 14
Figure 2-7 on
page 14
PM S-R power module with status-reset CAPAROC PM S-R Figure 2-8 on
page 15
Figure 2-9 on
page 15
E1 1-channel circuit breaker CAPAROC E1 12-24DC/1-10A Figure 2-10 on
page 16
Figure 2-11 on
page 16
E2 2-channel circuit breaker CAPAROC E2 12-24DC/2-10A Figure 2-12 on
page 17
Figure 2-13 on
page 17
E4 4-channel circuit breaker CAPAROC E4 12-24DC/1-10A Figure 2-14 on
page 18
Figure 2-15 on
page 18
PD 0V 0 V potential distributor CAPAROC PD 0V Figure 2-16 on
page 19
Figure 2-17 on
page 19
