Connecting or removing cables
109745_en_01 PHOENIX CONTACT 29 / 66
5 Connecting or removing cables
5.1 Connecting cables
All the connections of the CAPAROC system feature Push-in connection technology, en-
abling tool-free and above all fast and safe wiring.
Connect the network cable for the CAPAROC PM PN to the power module via an RJ45 con-
nector.
Please observe the following during wiring:
Make sure to install the conductor in the middle of the wiring space.
If you are using ferrules, comply with the specifications described in the module-spe-
cific documentation. Make sure that the ferrules are crimped correctly.
5.2 Connecting the power supply
5.2.1 Requirements for the power supply
Choose a power supply unit that is suitable for the currents in your application. The selection
depends on the system configuration and the resulting maximum currents.
WARNING: Loss of electrical safety when using unsuitable power supplies.
Dangerous shock currents.
The CAPAROC system is designed exclusively for protective extra-low voltage
(PELV) operation in accordance with EN 60204-1. Only protective extra-low voltage
in accordance with the defined standard may be used for supply purposes.
Only use power supply units that ensure safe isolation in accordance with
EN 50178 and EN 64010-2-201. They prevent short circuits between the primary
and secondary circuit.
WARNING: Dangerous contact voltage in the event of ground faults
The CAPAROC modules for the low-voltage area must only be operated in ground-
ed networks.
