CAPAROC system
38 / 66
PHOENIX CONTACT 109745_en_01
7.1.2 Output process data slot 0/subslot 2 (global system data)
The reset command switches all channels that were shut down by a short circuit or overload
back on. The command is issued once by setting bit “0” to “1”. To send another reset com-
mand, first set bit 0 to “0”. Then set bit 0 to “1” again.
Table 7-2 Output process data slot 0/subslot 2
Byte
offset
Data
type
Bit Description Value range
0 Byte 0 Global reset 0 = no reset command
1 = reset command for tripped channels
1 ... 7 Reserved 0
