CAPAROC E4 ... circuit breaker
Figure 2-14 Design of CAPAROC E4 ...
Figure 2-15 Dimensional drawing of CAPAROC E4 ...
1 LED button channel 1 6 Load output channel 2
2 LED button channel 2 7 Load output channel 3
3 LED button channel 3 8 Load output channel 4
4 LED button channel 4 9 Release
5 Load output channel 1
1
2
3
4
5
6
9
7
8
111,3
132,4
12,4
