Page #46 background image
CAPAROC system
46 / 66
PHOENIX CONTACT 109745_en_01
7.2.1.3 Global switch-on delay (index 000D
hex
)
The switch-on delay configures the time interval between switching on channels. The val-
ues listed below can be selected in the engineering with the GSD. The switch-on delay can
also be freely programmed with the acyclic WRREC block (except for value 65535/FFFF-
hex
).
The delay applies to all circuit breaker modules in the system.
* Depending on the system, there is always a delay of a few milliseconds
7.2.1.4 Global operating mode (index 000E
hex
)
This index configures the operating mode of the device after the voltage reset. In indepen-
dent operation, the channels that were switched on prior to the voltage reset are switched
on again. In the case of the “Wait for fieldbus” option, the output channels are only switched
on again once the PROFINET connection has been established.
Table 7-11 Global switch-on delay
Byte
offset
Data
type
Data Access Default setting
0 Word Delay (HIGH byte) Possible settings: r/w 50
0 = minimum delay*
25 = 25 milliseconds
50 = 50 milliseconds
1 Delay (LOW byte) 100 = 100 milliseconds
150 = 150 milliseconds
200 = 200 milliseconds
500 = 500 milliseconds
65535 = no change
Table 7-12 Global operating mode
Byte
offset
Data
type
Data Access Default setting
0 Byte 0 = independent operation r/w 0
1 = wait for fieldbus
2 = no change
