CAPAROC system
48 / 66
PHOENIX CONTACT 109745_en_01
7.2.2 Parameters and acyclic data slot 1 ...16
Read and write access for the following parameters is always 4 bytes long.
7.2.2.1 Nominal current setting (index 0001
hex
)
This index can be used to read and write the nominal current setting. The read or write com-
mand must be issued to the slot that corresponds to the module position in the system. The
subslot is always “1”.
* The nominal current is only adopted if the rotary switch is in the “RC” position (see Section , “CAPAROC E2 ...
circuit breaker”)
Table 7-14 Nominal current setting
Byte
offset
Data
type
Data Access Default setting
0 Byte 0 = no change r/w 2
{1 ... 10} = nominal current channel 1*
1 0 = no change
{1 ... 10} = nominal current channel 2*
2 0 = no change
{1 ... 10} = nominal current channel 3*
3 0 = no change
{1 ... 10} = nominal current channel 4*
