Updating the CAPAROC PM PN firmware
109745_en_01 PHOENIX CONTACT 53 / 66
8 Updating the CAPAROC PM PN firmware
8.1 General information
The CAPAROC PM PN front module (item number 1110986) can be updated.
Use at least version 2.30.72 of the PC WORX FIRMWARE UPDATER software for this.
Install the software on your PC.
You will find the latest version of the PC WORX FIRMWARE UPDATER software, and
the user manual for the software, in the download area at phoenixcontact.net/prod-
uct/2403718.
Communication protocols (DCP, ICMP, TFTP, and SNMP) are used to search for and iden-
tify the devices. They may be blocked by a firewall.
If necessary, disable the firewall on your PC.
Interface to other systems
Interface to other systems
8.2 Preparing the update
Start the PC WORX FIRMWARE UPDATER.
Click on “File...”.
Table 8-1 Interface to other systems
Descrip-
tion
Communi-
cation
partner
Zone Network
protocol
Proto-
col type
Usable
port num-
ber
Direc-
tion
Communi-
cation
channel
encryption
Authenti-
cation
PROFINET
device
PN IO con-
troller (PLC)
PLC area PROF-
INET, DCP,
LLDP
Incom-
ing/out-
going
No No
FW update PC WORX
FIRM-
WARE UP-
DATER
software
PLC
area/inter-
nal net-
work, de-
pending on
the routing
rules
ICMP,
SNMP,
TFTP
TCP 161, 69 Incom-
ing/out-
going
No No
Web server Browser PLC
area/inter-
nal net-
work, de-
pending on
the routing
rules
HTTP,
WebSock-
ets
TCP 80 Incom-
ing/out-
going
No No
