Mounting and removing modules

109745_en_01 PHOENIX CONTACT 27 / 66

4.6 Mounting distances

Leave enough space below the system to connect all the cables.

Maintain a minimum distance of 30 mm above and below to ensure adequate convec-

tion cooling.

Figure 4-4 Mounting distances for the CAPAROC system

190
