CAPAROC system
42 / 66
PHOENIX CONTACT 109745_en_01
7.1.7 Input process data of CAPAROC E4 12-24DC/1-10A
A block of 3 bytes of input process data is transmitted for each channel on the device. The
CAPAROC E4 12-24DC/1-10A 4-channel circuit breaker module therefore has 12 bytes of
input process data.
Table 7-7 Input process data of CAPAROC E4 12-24DC/1-10A
Byte
offset
Data
type
Bit Description Value range
0 Byte 0 Switching status, channel 1 0 = channel is switched off
1 = channel is switched on
1 Warning 80% I
Nom
, channel 1 0 = warning inactive
1 = warning active
2 Overload, channel 1 0 = no error
1 = overload shutdown
3 Short circuit, channel 1 0 = no error
1 = short-circuit shutdown
4 Defect, channel 1 0 = no defect
1 = hardware is defective
5 ... 7 Reserved 0
1 Byte 0 ... 7 Set nominal current, channel 1 {1 ... 10} A
2 Byte 0 ... 7 Flowing current, channel 1 0 ... 255 (= 0 ... 25.5 A)
3 Byte 0 Switching status, channel 2 0 = channel is switched off
1 = channel is switched on
1 Warning 80% I
Nom
, channel 2 0 = warning inactive
1 = warning active
2 Overload, channel 2 0 = no error
1 = overload shutdown
3 Short circuit, channel 2 0 = no error
1 = short-circuit shutdown
4 Defect, channel 2 0 = no defect
1 = hardware is defective
5 ... 7 Reserved 0
4 Byte 0 ... 7 Set nominal current, channel 2 {1 ... 10} A
5 Byte 0 ... 7 Flowing current, channel 2 0 ... 255 (= 0 ... 25.5 A)
