Process, parameter, and diagnostic data
109745_en_01 PHOENIX CONTACT 43 / 66
6 Byte 0 Switching status, channel 3 0 = channel is switched off
1 = channel is switched on
1 Warning 80% I
Nom
, channel 3 0 = warning inactive
1 = warning active
2 Overload, channel 3 0 = no error
1 = overload shutdown
3 Short circuit, channel 3 0 = no error
1 = short-circuit shutdown
4 Defect, channel 3 0 = no defect
1 = hardware is defective
5 ... 7 Reserved 0
7 Byte 0 ... 7 Set nominal current, channel 3 {1 ... 10} A
8 Byte 0 ... 7 Flowing current, channel 3 0 ... 255 (= 0 ... 25.5 A)
9 Byte 0 Switching status, channel 4 0 = channel is switched off
1 = channel is switched on
1 Warning 80% I
Nom
, channel 4 0 = warning inactive
1 = warning active
2 Overload, channel 4 0 = no error
1 = overload shutdown
3 Short circuit, channel 4 0 = no error
1 = short-circuit shutdown
4 Defect, channel 4 0 = no defect
1 = hardware is defective
5 ... 7 Reserved 0
10 Byte 0 ... 7 Set nominal current, channel 4 {1 ... 10} A
11 Byte 0 ... 7 Flowing current, channel 4 0 ... 255 (= 0 ... 25.5 A)
Table 7-7 Input process data of CAPAROC E4 12-24DC/1-10A
Byte
offset
Data
type
Bit Description Value range
