Phoenix Contact CAPAROC Series User Manual

The CAPAROC product family
109745_en_01 PHOENIX CONTACT 17 / 66
CAPAROC E2 ... circuit breaker
Figure 2-12 Design of CAPAROC E2 ...
Figure 2-13 Dimensional drawing of CAPAROC E2 ...
1 LED button channel 1 5 Load output channel 1
2 Rotary switch channel 1 6 Load output channel 2
3 LED button channel 2 7 Release
4 Rotary switch channel 2
1
2
3
4
5
6
7
111,3
132,4
12,4
