Process, parameter, and diagnostic data
109745_en_01 PHOENIX CONTACT 49 / 66
7.2.2.2 Local programming lock (index 0002
hex
)
This index can be used to read and write the local programming lock. The read or write com-
mand must be issued to the slot that corresponds to the module position in the system. The
subslot is always “1”.
7.2.2.3 Channel outputs (index 0003
hex
)
This index can be used to switch the channels of a module on and off. The read or write
command must be issued to the slot that corresponds to the module position in the system.
The subslot is always “1”.
Table 7-15 Local nominal current programming lock
Byte
offset
Data
type
Data Access Default setting
0 Byte 0 = channel 1 lock inactive r/w 0
1 = channel 1 lock active
2 = no change
1 0 = channel 2 lock inactive
1 = channel 2 lock active
2 = no change
2 0 = channel 3 lock inactive
1 = channel 3 lock active
2 = no change
3 0 = channel 4 lock inactive
1 = channel 4 lock active
2 = no change
Table 7-16 Channel outputs
Byte
offset
Data
type
Data Access Default setting
0 Byte 0 = switch off channel 1 r/w 0
1 = switch on channel 1
2 = no change
1 0 = switch off channel 2
1 = switch on channel 2
2 = no change
2 0 = switch off channel 3
1 = switch on channel 3
2 = no change
4 0 = switch off channel 4
1 = switch on channel 4
2 = no change
