Status Indicator LEDs
USER SW
Programmable Switch
Handle
I/O PORT
I/O Port Connector
DC18-36V 210VA
Power Supply Connector
GIGABIT ETHER
Gigabit Ethernet
LAN Cable Connector
POWER SW
Power Switch
Handle
G type F Mount Front
Front
Back
FASTCAM SA-Z FAST Drive model
KEYPAD
KEYPAD Connector
USB3.0 Connector
VIDEO OUT
Video Output Connector
FAST Drive Mount
FAST Drive
Mount Front Locks
FAST Drive Connector
HD SDI
HD SDI Output Connector
9 FASTCAM SA-Z Hardware Manual
