5.1.2. General Specifications
Environment Conditions
Storage Temperature
-20 ℃ - 60 ℃ (No Condensation)
-4ºF - 140ºF (No Condensation)
Storage Humidity
85% or less (No Condensation)
Operating Temperature
0 - 45℃ (No Condensation)
32ºF - 104ºF (No Condensation)
Operating Humidity
85% or less (No Condensation)
Pollution degree
Degree 2 according to IEC60664-1
Overvoltage category
Category II according to IEC60664-1
Maximum use altitude
2,000m or lower
External Dimensions
Camera Body
261.6 (H) x 150 (W) x 375.4 (D) mm, excluding protrusion
10.3" (H) x 5.9" (W) x 14.8" (D)
Camera Body
(FASTDrive model)
261.6 (H) x 175.5 (W) x 375.4 (D) mm, excluding protrusion
10.3" (H) x 6.9" (W) x 14.8" (D)
AC Adapter
37 (H) x 88.5 (W) x 218 (D) mm, excluding protrusion
1.5” (W) x 3.5” (H) x 8.9” (D)
AC Power Supply
Supply Voltage
100V - 240V (type A cable: up to 125V)
Supply Frequency
50Hz - 60Hz
Power Consumption
230W
DC Power Supply
Power Voltage
20V - 36 V
Power Consumption
230VA
Weight
Camera Body
10.4 kg 22.93 lbs, excluding protrusion
Camera Body
(FASTDrive model)
11.1 kg 24.47 lbs, excluding protrusion
AC Adapter
1.0 kg 35.27 oz.
Photron has verified two types of AC cables, type A (standard for Japan, USA, Canada, etc.)
and type SE (standard for Germany, France, etc.). However, when those cables cannot properly
receive power when plugged in, use the proper AC cable for the region's standards and verify
that AC cable works properly.
For inquiries regarding the recommended AC cable for each region, contact that region's
Photron branch office or the distributor.
