Photron FASTCAM Mini GigabitEthernet Interface User Manual

Chapter. 5 Product Specifications
5.1. Specifications
5.1.1. Product Specifications
Image Sensor
CMOS image sensor
Sensor Resolution
1,024 x 1,024 pixels
Frame Rate
For full frame operation: 20,000 fps maximum
For segmented frame operation:
FASTCAM SA-Z (type 2100K): 2,100,000 fps maximum
FASTCAM SA-Z (type 480K): 480,000 fps maximum
FASTCAM SA-Z (type 200K): 224,000 fps maximum
FASTCAM SA-Z (type 200KS): 224,000 fps maximum
Lens Mount
F mount (G type), C mount, EF mount (optional)
G type F mount, C mount, EF mount (optional)
Recording Color Depth
Monochrome
12bit / 8bit
Color
RGB, each 12bit / 8bit(Bayer color filter method)
Shutter Method
Electronic shutter
Recording Method
IC memory
Recording Memory Capacity
8 GB (type 1), 16 GB (type 2), 32 GB (type 3) , 64 GB (type 4)
Trigger Method
START, CENTER, END, MANUAL, RANDOM
RANDOM RESET, RANDOM CENTER, RANDOM MANUAL
Gain Control
Hardware LUT on camera
Controllable via Remote Controller or software
Image Output Customization
Customizable LUT, brightness is changeable
External Synchronization
Input Signal
+3.3 to +12Vp-p, negative polarity/positive polarity (switchable)
External Synchronization
Output Signal
5 Vp-p, negative polarity/positive polarity (switchable)
Trigger Input Signal
TTL(+3.3 to +12V), contact
Other Output Signals
Other timing signal outputs
External Control
Remote Controller, RS-422 external control I/F,
Gigabit Ethernet I/F (PC)
Video Output Signal
NTSC/PAL,
HD SDI (Compliant with SMPTE 292M)
-(NTSC mode)
1080i / 60Hz , 59.94Hz
1080p / 30Hz , 29.97Hz , 24Hz , 23.98Hz , 24Hz(sF) ,
23.98Hz(sF)
-(PAL mode)
1080i / 50Hz
1080p / 25Hz , 24Hz , 23.98Hz , 24Hz(sF) , 23.98Hz(sF)
With digital zoom, scroll, fit functions
Digital Interface
Gigabit Ether x2 Port(1000BASE-T), SD Card Slot
FAST Drive Option
80

Photron FASTCAM Mini GigabitEthernet Interface Specifications
