3.29. Direct Trigger / Direct Start Mode
The system recording operation responding to an input trigger signal can be configured according to
varies of customer’s needs.
• DIRECT TRIGGER Mode (This mode is NOT supported on PFV software)
• START TRIGGER Mode
Recording starts immediately upon the second trigger input.
• CENTER, END, MANUAL TRIGGER Mode
Once the trigger signal is input, the camera will be shifted to endless recording state.
• DIRECT START Mode
• START TRIGGER Mode
The same operation as when the direct trigger mode is off.
• CENTER, END, and MANUAL TRIGGER Modes
Once the trigger signal is input, the camera is shifted to endless recording state. In this
circumstance, either the “RECORD” button of PFV software or the GENERAL IN
Connector under ReadyPos state, furthermore the “RECORD” button of LCD Remote
Controller can trigger a record signal to the camera.
•
For details of how to set the camera to DIRECT START Mode, refer to “Remote Controller User’s
Manual” or “Photron FASTCAM Viewer User’s Manual”.
•
For details of GENERL IN signal settings, refer to “3.20.1. GENERAL IN Signal Settings”.
•
When using Direct Trigger, existing memory data is overwritten immediately as soon as a trigger is
input.
71 FASTCAM SA-Z Hardware Manual
