2.2.5. Remote Controller (Optional)
The system can be operated while checking the monitor by connecting the optional remote
controller to the "KEYPAD" connector on the rear of the camera body. The remote controller is also
hot-pluggable; it can be plugged into and unplugged from the camera while the power is on.
Camera Body
Connector
Signal
Camera Body Connector
Model Name
(Manufacturer)
Keypad Connector
Model Name
(Manufacturer)
KEYPAD Keypad signal
ECG.2B.310.CLN
(LEMO)
S22L0C-P10MJG0-820S
(ODU)
•
The remote controller is optional. It is not included in the standard configuration.
•
For how to operate of the Remote Controller, refer to "Remote Controller User's Manual".
『VIDEO OUT terminal』
13 FASTCAM SA-Z Hardware Manual
