Chapter. 3 Recording
3.20.2. GENERAL OUT Signal Settings
Details of the signals output from the GENERAL OUT connector explained in section “3.17. Contact
Information” are shown in the chart below. There are three GENERAL OUT connectors and
individual settings can be made for each connector.
SYNC POS
Outputs a positive polarity vertical synchronization
+5V CMOS output,
SYNC NEG
Outputs a negative polarity vertical synchronization
+5V CMOS output,
EXPOSE POS Outputs the sensor's exposure interval at H level.
+5V CMOS output,
EXPOSE NEG Outputs the sensor's exposure interval at L level.
+5V CMOS output,
REC POS Outputs an interval signal during recording at H level.
+5V CMOS output,
REC NEG Outputs an interval signal during recording at L level.
+5V CMOS output
TRIG POS
Outputs the trigger signal received by the camera at H
+5V CMOS output,
TRIG NEG
Outputs the trigger signal received by the camera at L
+5V CMOS output,
READY POS
Outputs a signal at H level during the trigger wait state.
(READY in START mode.) Only valid during START,
CENTER, END, and MANUAL modes.
+5V CMOS output,
Positive Polarity
READY NEG
Outputs a signal at L level during the trigger wait state.
(ENDLESS recording state in CENTER, END, MANUAL)
Only valid during START, CENTER, END, and MANUAL
modes.
+5V CMOS output,
Negative Polarity
IRIG RESET POS
Outputs the camera's internal IRIG reset signal (1PPS)
+5V CMOS output,
IRIG RESET NEG
Outputs the camera's internal IRIG reset signal (1PPS)
+5V CMOS output,
STRADDLING Outputs pulse signals for STRADDLING.
+5V CMOS output,
When using as a part of a system, verify the characteristics of the output signals before using
them.
