Photron FASTCAM Mini GigabitEthernet Interface User Manual

Chapter. 3 Recording
3.1.4. The operation of the Mechanical shutter
When using the Mechanical shutter, there is no need to shade the light since the shutter will close
automatically when carrying out a calibration.
•
Mechanical shutter option physically restricts available dimension of C-mount lens.
- Projection from the lens mount flange plane (a): maximum 4 mm
- Diameter (b) :maximum 80 mm
(a)
(b)
26
