Pinnacle Systems, Inc. TARGA 3000 Cookbook

TARGA 3000 Configuration Cookbook
11/25/2002 13
3.13 IBM Intellistation Mpro model 6868-xxU
IBM Product Information
32-bit PCI solution from IBM.
Tested Configuration
- BIOS version PLKT 33.0 dated 05/18/00
- Model 6868-52U
- One Pentium III 866MHz "Coppermine" 133 MHz
FSB
- 256 MB RDRAM 133 MHz
- Matrox Millenium G400 single or dual head 32MB
display adapter
- Adaptec 29160 SCSI host adapter
+ check Seven Quantum Atlas 10K 9WLS Ultra160m
9 GB drives
BIOS Settings:
Required BIOS Changes
Performance Rating
2 streams YUV uncompressed
Slot Positions
AGP: Matrox G400
PCI 1: empty
PCI 2: empty
PCI 3: TARGA 3000
PCI 4: empty
PCI 5: Adaptec SCSI host adapter
Technical Advisories
1. PCILOCK Boot Option
Specifications and Features
Architecture:
Form factor Mini tower (6x7)
Orientations allowed Vertical
Slots x bays total (free) 6(4) x 7(4)
Expansion bus type PCI
Processor:
Processor (CPU) Pentium III
Processor internal clock speed1 866 MHz
Planar clock speed 133 MHz
SMP processors std 1
SMP processors max 2
Upgradable processor No
Math co-processor Built-in
L1 internal CPU cache 128 KB
Processor upgrade options SMP via second Pentium
III
SMP capable (multiple processors) Yes
L2 cache std 256KB
L2 cache max 256KB
BIOS type Flash ROM
Memory:
Memory (RAM) std 256 MB
Memory (RAM) max3 1024 MB
RAM speed 300MHz
RAM type PC 600 ECC RDRAM
RAM slots total 4 RIMM
RAM slots available 2 RIMM
Expansion options:
Slots total (free) and type 1(0) AGP fullsize, 5(4) PCI
fullsize
3.5 inch bays - accessible (free) and height 2(1)
3.5 inch bays - not accessible (free) and height 3(2)
5.25 inch bays - accessible (free) and height 2(1)
5.25 inch bays - not accessible (free) and height 0(0)
