TARGA 3000 Configuration Cookbook
11/25/2002 29
4.3 Supermicro S370DL3
Supermicro S370DL3 site
Tested Configuration
+ Two Pentium III 733MHz 133 Mhz FSB
+ 512 MB PC-133 Registered ECC PC-133 SDRAM
+ ATI Rage 128 Pro PCI 16MB display adapter
+ Adaptec 29160 SCSI host adapter BIOS v2.55.0
+ Adaptec 39160 Dual Channel SCSI host adapter
+Qlogic Dual Channel SCSI QLA12160 Host
Adapter
+IWILL DU3160 Dual Channel SCSI Host Adapter
(Dual Channel external connection requires an
additional internal to external adapter cable.)
+ Integrated Intel 82559 Network Controller
+ 8 Quantum Atlas 10K 9WLS Ultra160m 9 GB
drives
Performance Rating
3 streams YUV uncompressed
Slot Positions
Note: Slot closest to AGP is PCI 5
PCI 64-2: Targa 3000
PCI 64-1: AHA-39160
PCI 32-4: Empty
PCI 32-3: Empty
PCI 32-2: ATI Rage Pro 128 PCI
PCI 32-1: Empty
ISA 1 : Empty
Technical Advisories
1. PCILOCK Boot Option
2. Since this workstation uses the serverworks
chipset, only PCI VGA adapters can be
used, not AGP
Specifications and Features
Form Factor - ATX with PC99 color-coded double-
deck I/O- Size: 12" x 10.25" (W x H)
Processor Support - Dual or single Intel 370-pin
Pentium III FCPGA 600-933 MHz processors
Chipset - ServerWorks ServerSet III LE Chipset.
Front Side Bus (FSB) 133 /100 MHz
Memory - Four 3.3 volt, 168-pin registered DIMM
sockets (PC100 or PC133). Up to 4 GB registered
ECC DIMMs
Note: Supports only registered ECC memory. Non-
ECC or unbuffered SDRAM not supported.
I/O Expansion Slots
Two 64-bit, 66/33 MHz PCI bus mastering slots
Four 32-bit PCI bus mastering slots at 33 MHz
One 16-bit ISA slot
Onboard Devices
Onboard Intel 82559 Ethernet controller
Onboard Adaptec AIC-7892 single channel
Ultra3/160 SCSI controller Two Ultra DMA
(UDMA/33) bus master/EIDE channels support data
transfer rates of up to 33 MB/sec Dual USB
(Universal Serial Bus) ports PS/2 keyboard and PS/2
mouse connectors
Two 16550 UART compatible serial ports
One ECP/EPP parallel port
One floppy port
Other Features
One WOL (Wake-On-LAN) connector
One chassis intrusion connector
Chassis Compatibility
Extended ATX chassis
Fits Super Micro SC750-A, SC760, and
SC830chassis
