TARGA 3000 Configuration Cookbook
11/25/2002
62
7.6 Certified Hard Drives (JBOD applications)
The following list of drives have been tested by Pinnacle Systems Certification process and are proven to perform well
with Targa 3000 under Premiere 5.1c and 6.0 environment. With the exception of U2W drives, when 8 of the same
units are striped with a 64 bit enabled U160 SCSI interface, under optimal cabling (namely SCSI connection and
termination), cooling condition and driver configuration, end users can obtain 3 YUV streams real time playback under
Premiere environment for at least 25% of physical drive surface.
BRAND MODEL CAPACITY INTERFACE
IBM DRVS-09 9.1 GB U2W
IBM DMVS-09D 9.1GB SCA-2 U2W
IBM DDYS-T18350 18.35 GB SCA-2 U160
IBM DDYS-T36950 36.7GB SCA-2 U160
IBM DESKSTAR 120GXP 80 GB U160
IBM DESKSTAR 40 GB U160
QUANTUM ATLAS 10K II 9.1 9.1 GB U160
QUANTUM ATLAS 10K II 18.2 18.2 GB U160
QUANTUM ATLAS 10K III 18.4 GB U160
QUANTUM ATLAS V 36.4 GB U160
SEAGATE ST39102LW 9.1GB U2W
SEAGATE ST39205LW 9.1GB U160
SEAGATE ST39204LW 9.1GB U160
SEAGATE ST318404LC 18.4GB SCA-2 U160
SEAGATE ST318404LW 18.4GB U160
SEAGATE ST318452LC 18.4GB SCA-2 U160
SEAGATE ST318452LW 18.4GB U160
SEAGATE ST318451LW 18.4GB U160
SEAGATE ST336705LW 36.7GB U160
SEAGATE ST336752LW 36.7GB U160
SEAGATE ST336704LW 36.7GB U160
SEAGATE
ST336706LC 36 GB
U160
Drives marked in red are newly certified.
Note : Some Seagate drives require that the Cache Parameters to be changed from Desktop Mode to
Server mode using Seagate’s SeaTools software in order to perform well with 3 streams operations. Please
refer to the following link to acquire more instructions:
http://www.pinnaclesys.com/support/faq/ViewFAQ_US.asp?id=3158&lge_id=1
7.7 System Boot Drives
Use the fastest system drive you can install in your system, from SCSI Ultra3 to ATA UDMA 66 (UltraDMA)
EIDE drives. We recommend drives sizes of 9 GB or higher. Generally, the SCSI drive alternative will
provide faster performance due to command queuing, but 66MHz UltraDMA drives are adequate. Be sure to
apply the latest UltraDMA driver from the motherboard manufacturer, as Windows NT 4.0 does not natively
support UltraDMA.
