Pinnacle Systems, Inc. TARGA 3000 Cookbook

TARGA 3000 Configuration Cookbook
11/25/2002 55
7.5.1 Rorke Data MaxArray LVD
Rorke Data MaxArray LVD Product Information
Performance Rating
4-drive: 2 streams YUV uncompressed
8-drive: 3 streams YUV uncompressed
Drives:
IBM Ultra160m SCSI LVD
160 MB/sec bus speed
Split-Bus (8 bay only)
Capacity:
MaxArray configurations range from 18GB through 576GB.
Enclosure:
SCA Backplane technology in 4 Bay Tower, 8 Bay Tower, and 8 Bay Rack configurations.
All-metal enclosure for maximum heat-dissipation.
Locking front door for added security.
Hot-swappable canisters.
4 Bay - 150W removable power supplies and removable, ball-bearing fan.
8 Bay - Qty (2) 300W hot-swappable power supplies and (2) removable, ball-bearing fans.
LVD SCSI ID settings accessibility.
Auto-sensing termination.
Audible and visual alarms for fan, temperature and power fail LED.
Featuring SCA (Single Connect Attachment) Backplane Technology
- As data transmission rates get faster and faster, bus impedance matters. Rorke Data's SCA
backplane design reduces impedance on the data bus resulting in increased signal integrity and
better performance at these higher speeds. Where it makes sense, we have taken the time to match
impedance characteristics to limit the amount of signal reflections causing unwanted noise on the
bus which can further degrade signal integrity. In addition, SCA backplane reduces the number of
internal connection points which significantly improves long-term reliability
