TARGA 3000 Configuration Cookbook
11/25/2002
34
4.8 INTEL D850GB
INTEL D850GB
D850GB HOMEPAGE
PERFORMANCE RATING:
2 streams YUV uncompressed
TESTED CONFIGURATION:
+Pentium 4 1.5 400 Mhz FSB
+512 MB PC800 RAMBUS RDRAM
+ATI RAGE 128 32MB AGP VGA
+Adaptec 29160 SCSI host adapter BIOS
v2.55.0
+Adaptec 39160 Dual Channel SCSI host
adapter
+Qlogic Dual Channel SCSI QLA12160 Host
Adapter
+IWILL DU3160 Dual Channel SCSI Host
Adapter(Dual Channel external connection
requires an additional internal to external
adapter cable.)
+Integrated Intel 82559 Network Controller
+8 Quantum Atlas 10K 9WLS Ultra160m 9 GB
drives
SLOT ASSIGNMENTS:
AGP : ATI Rage 128 AGP VGA
PCI32-5: Adaptec AHA-29160
PCI32-4: Empty
PCI32-3: Empty
PCI32-2: TARGA 3000
PCI32-1: Empty
Note: PCI32-5 is closest to AGP slot
CONFIGURATION NOTES:
Use PCILOCK function if running Windows NT
4.0.
FEATURES AND SPECIFICATIONS:
Form Factor:
ATX (12.0 inches by 9.6 inches)
Supported Processors:
Support for an Intel® Pentium® 4 423 Pin processor
400 MHz system data bus
Memory Type:
Two Direct-RDRAM channels with two RIMMs per
channel (four RIMM sockets)
Support for up to 2 GB of system memory using PC600
or PC800 RDRAM
Chipset:
Intel® 850 Chipset, consisting of:
Intel® 82850 Memory Controller Hub (MCH)
Intel® 82801BA I/O Controller Hub (ICH2)
Intel® 82802AB 4 Mbit Firmware Hub (FWH)
I/O Expansion Slots:
One 4xAGP slot
Five PCI bus add-in card connectors (SMBus routed to
PCI bus connector 2)
Integrated Devices:
Audio subsystem that uses the Analog Devices AD1881
analog codec for AC 97 processing
Intel® 82562EM 10/100 Mbit/sec Platform LAN Connect
(PLC) device
Two Ultra DMA (UDMA/100) bus master/EIDE
channels that support an IDE drive data transfer
rate of 100 MHz
4 USB (Universal Serial Bus) ports (two onboard
connectors and two headers)
PS/2 keyboard and PS/2 mouse connectors
Two fast UART 16550 compatible serial ports
One ECP/EPP parallel port
One floppy port
Chassis Compatibility:
Standard ATX chassis
