Pinnacle Systems, Inc. TARGA 3000 Cookbook

TARGA 3000 Configuration Cookbook
11/25/2002 20
3.20 HP Workstation X4000
HP Workstation X4000
HP Workstation X4000 Homepage
PERFORMANCE RATING: 3 streams YUV
TESTED CONFIGURATION:
+2 x 1.7GHz Intel Xeon Processors
+1 GB PC800 RDRAM Rambus Memory
+Integrated LSI Logic 53C1010 Dual Channel
SCSI 160 Controller
+Nvidia Quadro 2 Pro AGP video adapter with
64MB
+Adaptec AHA-39160 Dual Channel SCSI 160
Controller with firmware number 2.57.2
+8 Quantum Atlas 10K 9WLS Ultra160m 9 GB
drives
SLOT ASSIGNMENTS:
AGP: NVIDIA Quadro 2 Pro
PCI32-1: Empty
PCI32-2: Empty
PCI32-3: Empty
PCI64-1: Targa 3000 (Rev. D)
PCI64-2: AHA 39160
CONFIGURATION NOTES:
1. Busmaster must be enabled in all PCI
Slots (by default, HP has busmaster
disabled in all PCI slots.) Please
consult the user manual on how to
enable busmaster in the BIOS.
2. Targa 3000 (model 3105) is tested and
passed.
FEATURES AND SPECIFICATIONS:
Form Factor:
Extended ATX footprint (13" x 12")
Supported Processors:
Supports dual/single Intel® XeonTM(Socket 603)
processor
400 MHz Front Side Bus
Memory Type:
PC800 Rambus RDRAM Memory Expandable to 4GB
Chipset:
Intel
®
860 chipset
82860 North Bridge,
82801BA I/O Controller Hub,
82802AB Firmware Hub
and 82806AA PCI 64 Hub
I/O Expansion Slots:
1 AGP 4X
3 PCI 32 Bit Slots
2 PCI 64 Bit Slots
Integrated Devices:
Integrated 10/100 ethernet controller
Integrated dual channel ATA 100 IDE controller
Integrated dual channel LSI Logic 53C1010 SCSI 160
controller
Integrated AC’97 Audio Codec
