TARGA 3000 Configuration Cookbook
11/25/2002
28
4.2 Supermicro P6DBE 440BX motherboard
Supermicro P6DBE site
Tested Configuration
- BIOS version 4060 release 3.0
- Board version 3.0
+ Two Pentium III 550MHz 100 Mhz FSB
+ 256 MB PC-100 SDRAM
+ ATI Rage 128 Pro AGP 32MB display adapter
+ (also tested with Matrox G400 16MB single head
display adapter)
+ Adaptec 29160 SCSI host adapter BIOS v2.55.0
+ 3Com905C-TX 10/100 network interface card
+ Creative Labs Sound Blaster PCI128 sound card
+ Seven Quantum Atlas 10K 9WLS Ultra160m 9 GB
drives
BIOS Settings:
Optimal settings with the following changes:
Power Management Mode: Disabled
Performance Rating
2 streams YUV uncompressed
Slot Positions
Note: Slot closest to AGP is PCI 5
AGP: display adapter (ATI or Matrox)
PCI 5: empty
PCI 4: TARGA 3000
PCI 3: Adaptec SCSI
PCI 2: 3Com905C-TX
PCI 1: Sound Blaster PCI128
ISA 1: empty
ISA 2: empty
Technical Advisories
1. PCILOCK Boot Option
Specifications and Features
The SUPER P6DBE, running at a bus speed of 100
MHz, supports dual Pentium III/II 233 ~ 700 MHz
processors. The P6DBE is based on Intel's 440BX
chipset, which enables AGP, 100 MHz SDRAM,
concurrent PCI, Ultra DMA with a 33 MB/s burst data
transfer rate and Wake-on-Lan.
The SUPER P6DBE (board rev 2.x, 3.x) comes with
5 PCI and 2 ISA slots and an AGP connector. AGP
reduces contention between the CPU and I/O
devices by broadening the bandwidth of graphics to
memory. It delivers a maximum 532 MB/s 2x transfer
mode, which is quadruple the PCI speed.
