TARGA 3000 Configuration Cookbook
11/25/2002
31
4.5 IWILL DCA200N
IWILL DCA 200N site
Tested Configuration
- BIOS version 715
- Board version 1.4
+ Two Pentium III Xeon 733 133 Mhz FSB
+ 256 MB RIMM Rambus Memory
+ Matrox G400 16MB single head display adapter)
+ Adaptec 39160 SCSI host adapter BIOS v2.55.0
+Qlogic Dual Channel SCSI QLA12160 Host
Adapter
+IWILL DU3160 Dual Channel SCSI Host Adapter
(Dual Channel external connection requires an
additional internal to external adapter cable.)
+ Integrated Intel 82559 Network Controller
+Integrated AC'97 Audio CODEC
+ 8 Quantum Atlas 10K 9WLS Ultra160m 9 GB
drives
BIOS Settings: Please make sure that MPS 1.1 is
used in advanced BIOS setup menu.
Performance Rating
3 streams YUV uncompressed
Slot Positions
Note: T3K is tested to work with either 64 bit PCI
Slots.
AGP: display adapter (ATI or Matrox)
PCI 32-4: empty
PCI 32-3: empty
PCI 32-2: empty
PCI 32-1: empty
PCI 64-2: AHA-39160
PCI 64-1: Targa 3000
Technical Advisories
1. PCILOCK Boot Option
2. There were reports of Targa 1394 port not
functional in Windows 2000. Please have
your TARGA card modified for OHCI driver
support or use an OHCI compliant car like
the DV Studio to take advantage of 1394.
Specifications and Features
Performance of DCA200 supporting dual 800 MHz
Intel(R) Pentium(TM) III Xeon(TM) processors
Chipset - Intel(R) 840 AGPset, Supports 133MHz /
100MHz FSB
Windbond(R) 83627-HF I/O set
Bus Frequency- "Bye-Bye Jumper(TM)", Iwill Smart
Setting. Supports 133/100MHz FSB
System Memory
4 x RIMM Sockets Support up to 2GB of RDRAM
Modules
Supports 64/128/256/512 MB RDRAM Module
Supports ECC Type and SPD RIMM Module
On Board IDE
Dual Ultra DMA 33/66 IDE Ports
Supports ATAPI IDE CD-ROM, ZIP-100 & LS-120
Expansion Slots
1 x AGP Pro Slot supports AGP Pro 50 and AGP 4X
2 x 64bit/66MHz PCI 2.2 Bus Master Slots
4 x 32bit/33MHz PCI 2.2 Bus Master Slots
BIOS
4MB PLCC FWH(Firmware Hub) with Flash
Board Size
WTX Form Factor - 360mm x 290mm,6 layers
