TARGA 3000 Configuration Cookbook
11/25/2002
21
3.21 Compaq Evo Workstation W8000 UPDATED, 11/25/02
COMPAQ EVO W8000
EVO W8000 Homepage
PERFORMANCE RATING: 3 streams YUV
TESTED CONFIGURATION:
BIOS revision and date - Compaq System ROM v01.05
OS and service pack info. - Windows2000 Professional
w/ sp1
BIOS settings – As shipped
1 x Pentium Xeon 1.7GHz
2 x 256MB ECC PC800 RDRAM
1 x Integrated AIC-7899 dual channel U160 SCSI controller
(DO NOT USE)
1 x Adaptec AHA-39160
1 x Nvidia Quadro 2 Pro AGP adapter
1 x Seagate 18GB U160 ST318451LW System drive
8 x Quantum Atlas 10K U160 Video Arrray
Certification Testing - tested with CODI 2.0B4 release and
Targa 3000 1.5/Premiere 6
CODI testing - ran all CODI examples
Targa testing - ran a 1 Hour 33 minute project to ~167,000
frames
Project1 consists of three YUV uncompressed streams
(one full screen w/ two overlayed PIPs) with five graphic
layers (Title Deko generated titles)
DV25 testing (capture and playback)
MPEG I-Frame (capture and playback)
Boards used for testing included the following:
CODI - TARGA3101 and TARGA3210
Targa 3000 v1.5 - TARGA3100
SLOT ASSIGNMENTS:
AGP: NVIDIA Quadro 2 Pro
PCI32-1: Empty
PCI32-2: Empty
PCI32-3: Empty
PCI32-4: Empty
PCI64-1: Targa 3000 (Rev. D)
PCI64-2: AHA 39160 (REQUIRED)
CONFIGURATION NOTES:
The internal AIC-7899 dual channel ultra160 SCSI3
controller was not used for video-data storage in this
testing due to it being attached to the 32-bit PCI bus.
With the TARGA3000 in a 64-bit PCI slot, the available
video-data bandwidth would be severely limited by this
data having to go through a PCI bridge before reaching
the ultra160 SCSI3 controller on the 32-bit PCI bus.
In order to pass the 90-minute Adobe Premiere playback
portion of the certification process without any dropped
frames, the following services should be disabled in the
"Services" control panel:
1. Altiris Client Service
2. Compaq DMI Web Alerter
3. Compaq Local Alerter
4. Compaq Remote Diagnostics Enabling Agent
5. Insight Manager LC Remote Management
With these services enabled, Our 90-minute playback test
was consistently dropping 4 - 7 frames.
FAILURE TO COMPLY WITH THESE CONFIGURATION
SUGGESTIONS MAY RESULT IN PINK/GREEN
FRAMES.
FEATURES AND SPECIFICATIONS:
Supported Processors:
Supports dual/single Intel® XeonTM(Socket 603)
processor
400 MHz Front Side Bus
Memory Type:
PC800 Rambus RDRAM Memory Expandable to 4GB
Chipset:
Intel
®
860 chipset
82860 North Bridge,
82801BA I/O Controller Hub,
82802AB Firmware Hub
and 82806AA PCI 64 Hub
I/O Expansion Slots:
1 x AGP Pro 4x
2 x 64-bit/66-MHz PCI
4 x 32-bit/33-MHz PCI
Integrated Devices:
Integrated Intel PRO/100+ Management Adapter
Integrated dual channel ATA 100 IDE controller
Integrated dual channel 160 controller
Integrated SoundBlaster 128 Audio
